CHARGING MODE 2 - Bidirectional 16A/250V AC

Electric Vehicle Connection

Features

Charging connector and mode 2 reference GB/T 20234 .1&2, GB 39752-2024, GB 44263-2024
Degrees of protection (Power strip): IP54 before insertion and IP55 after insertion
Degrees of protection (Charging connector): IP67 (working)

Get Quote

Machanical Performance

Machanical lifespan: no-load plug in/withdraw >10000 times

Impact resistance: withstands 1m drop and 2-ton run-over

Environmtal Performance: Operating temperature: -30℃~+60℃

Applied Materials: Case Material: Thermoplastic, flame retardant grade UL94 V-0

Electrical Performance

Rated current: Discharge 16A, charge 16A

Rated voltage: Discharge is 250V AC and charge is 250V AC

Insulation resistance: ≥100 MΩ (500V DC)

Terminal temperature rise: <50K

Withstand Voltage: 2000V/AC for 1 minute, leakage current ≤5mA

Contact Resistance: 0.5mΩ Max

Control Box Function

Leakage protection, Grounding protection, Overvoltage under-voltage protection,
Over-current Protection, Over-temperature protection, Outdoor protection,
Overfrequency and underfrequency protection, Short-circuit protection

Leakage protection: TYPE A 30mA + DC6mA

Standby power consumption: ≤3w

It also: TSL open cover 433MHz
