Control box meet IEC 62752 control principle
Vehicle connector meet IEC 62196 regulations and requirements
Power pulg meet VDE0620-1 regulations and requirements
Power plug: Multiple plug types optional
Degrees of protection: IP55 (working condition) Control box IP67
Machanical PerformanceMachanical lifespan: no-load plug in/withdraw > 10000 times
Impact resistance: withstands 1m drop and 2-ton run-over
Environmtal PerformanceOperating temperature: -30°C~+50°C
Applied MaterialsCase Material: Thermoplastic, flame retardant grade UL94 V-0
Electrical PerformanceRated current: 32A MAX (adjustable)
Operation voltage: 250V
Insulation resistance: >100MΩ (DC 1000V/1minute)
Terminal temperature rise: <50K
Withstand Voltage: 2500V AC/1 minut
Contact Resistance: 0.5mΩ Max
Control Box FunctionMulti color status indicator light
Multi current mode (replace mains plug)
Adjustable charging current 16/13A
Overvoltage under-voltage protection
Overcurrent protection
Control box over temperature protection
| Model | Rated Current | Cable Specification |
|---|---|---|
| 2080-IPSE-32-XC-ES | 32A | 3×6mm²+1×0.75mm²(TPU) |
Relying on self-developed leading intelligent charging regulation technology and multiple safety protection systems, it fully safeguards your charging experience. The products have passed multiple global authoritative certifications
