NACS AC CHARGING PLUG
Charging Station Electrical Connection
Features
Meet North American Charging Standard TS-0023666 SAE J3400 regulations and requirements
Elegant appearance, ergonomic design, easy to use
Degrees of protection: 4X, IP55
Machanical Performance-
Machanical lifespan: no-load plug in/withdraw >10000 times
Coupled insertion force: ≤ 100N
Impact resistance: withstands 1m drop and 2-ton run-over
Environmtal Performance-
Operating temperature: -30°C~+50°C
Applied Materials-
Case Material: Thermoplastic, flame retardant grade UL94 V-0
Contact Sleeve: Copper alloy, silver plated
Electrical Performance-
Rated current: 16A/32A/40A/50A/80A
Operation voltage: 300V
Insulation resistance: ≥100MΩ(DC 1000V/1 minute)
Terminal temperature rise: < 50K
Withstand Voltage: 2500V AC/1 minute
Contact Resistance: 0.5mΩ Max
Model selection and standard Cable
| Model | Rated Current | Cable Specification |
|---|---|---|
| DST-EV-80P | 80A (UL line) | 2×5AWG+1×8AWG+6×20AWG |
| DST-EV-40P | 40A (UL line) | 3×9AWG+1×16AWG |
| DST-EV-50P | 50A (UL line) | 2×8AWG+1×10AWG+1×16AWG |
| DST-EV-32P | 32A (UL line) | 3×6mm²+1×0.75mm² |
| DST-EV-16P | 16A (UL line) | 3*14AWG+1*18AWG |
