Application: Electric vehicle PDU, battery pack
The fuse and breaking device are combined into one, which is convenient for maintenance, repair and replacement.
Adopt direct insertion and mechanism buckle locking method
Reliable connection and easy disassembly
Using plastic shell, low cost and high output
Built-in high-voltage interlocking function, with two-level linkage interlocking structure, limited protection of automotive high-voltage circuits
Degrees of protection: IP67
Mechanical PerformanceInstallation method: screw locking
Electrical PerformanceRated voltage: 1000V DC
Rated current: 170A (Max)
Insulation resistance: >1000MΩ
Insulation withstand voltage: 3000V AC
Temperature rise：≤50K
Environmental PerformanceOperating temperature: -40℃~+125℃
Fusing current (A) | 200 | 250 | 350 | 400 | Remarks |
|---|---|---|---|---|---|
DH4-2P36-A200 | DH4-2P36-A250 | DH4-2P36-A350 | DH4-2P36-A400 | Plug | |
DH4-2R36-AM6 | Socket | ||||
