Controled with pulsed current, low power consumption
Small size, suitable for small space installation
In the event of a power outage or malfunction, can be manual unlocked
Motor driven
Non-disassemblable case degrees of protection: IP54
Machanical PerformanceMachanical lifespan: operating cycle >50000 times
Environmtal PerformanceOperating temperature: -30℃～+50℃
ApplicationGB/T and Type 1 Vehicle socket
Applied MaterialsCase Material: Thermoplastic, flame retardant grade UL94 V-0
Electrical PerformanceWorking current: Maximum current (locked rotor)
Maximum current: 1.0A (@ 16V, -40 °C)
Average operating current (unloaded): 0.5A (@ 12V, RT)
Voltage: 12V/24V
Drive-time: 300-400 ms
Execution time: Working time ≤ 600ms
Driving force: Top output force > 40N@RT, 12V; Holding force ≥ 40N
Release operating force: Emergency release lever operating force < 35N
Travel: Lock rod travel 5.0/8mm
Compatible ProductsXX-DSI-EV-S series GB/T socket and inlet
XX-DSS-EV-S series Type1 socket and inlet
XX-DSIEC3j-EV-S series CCS1 inlet on vehicle
| Model | Rated Current | Cable Specification | Connection principle |
|---|---|---|---|
| V5C-DSI-ELM | 12V 0.3A | 4 × 0.3mm² | Lock it. - Signal is on |
| V5C-DSI-ELM.1 | 12V 0.3A | 4 × 0.3mm² | Lock it. - Signal is on |
| V5C-DSI-ELM.2 | 12V 0.3A | 4 × 0.3mm² | Lock - Model disconnected |
